REMARKS :
#
The intake camshaft is similar to the exhaust camshaft to fit two adjustable (non VVT) pulleys.
When ordering, replace '4901xxx' by '4902xxx' (eg: 4901902 > 4902902)
#
FOR COMPETITION APPLICATIONS ONLY. Following details must be verified:
-
the camshafs must turn smooth in the cylinderhead, provide free travel by machining where needed
-
distance between valve seal and retainer at full lift must be 0.6mm at least
-
minimum valve spring travel of 1.0mm at full lift must be provided
-
distance between valve and piston 1.0mm (pref. 1.5mm). check 5-15° before TDC on exhaust, and after TDC on intake
#
ONLY for use in competition engines with independent engine management (throttle position sensor) or carburettors
#
evolution of 4902806
