REMARKS :
#
Both intake and exhaust cam driven by adjustable belt pulley (like oem exhaust cam). Without sprockets in the middle of the camshafts for connecting chain.
Pulley kit CTPO968 includes 2 cam pulleys, 1 crankshaft pulley and a Gates distribution belt.
#
FOR COMPETITION APPLICATIONS ONLY. Following details must be verified:
-
the camshafs must turn smooth in the cylinderhead, provide free travel by machining where needed
-
distance between valve seal and retainer at full lift must be 0.6mm at least
-
minimum valve spring travel of 1.0mm at full lift must be provided
-
distance between valve and piston 1.0mm (pref. 1.5mm). check 5-15° before TDC on exhaust, and after TDC on intake
#
ONLY for use in competition engines with independent engine management (throttle position sensor) or carburettors
#
for TURBO conversion (atmospheric to turbo)
