REMARKS :
#
- camshafts for use with CATCAMS slipper kit (cam lobes are not compatible with other rocker arm systems)
- cylinder head need to be machined to fit the rocker arm system (service available from CATCAMS)
- VVT delete camshaft set includes adjustable sprockets on both intake and exhaust camshaft.
#
valve seals must be lowered. Distance between valve seal and retainer must be at least 0.6mm at full lift.
#
Distance between valve and piston should be 1.0mm at least:
-
check 5-15° after TDC on intake
-
check 5-15° before TDC on exhaust
Machine pistons if required. Wrong installation can cause severe engine damage!
#
for BIG TURBO conversion (std to big turbo)
#
ONLY for use in competition engines with independent engine management (throttle position sensor) or carburettors
