Volkswagen BYD-BWJ-BHZ EA113 TFSI 230-240-265hp

I-4cyl 2.0L 16v DOHC (RPRH/RPRH)

#

machining of cylinder head NOT required

#

use PAC-D99864 dual valve spring + 99423 upper retainer + 99503 lower retainer for 88kg MAX possible load, requires head machining to clear outer diameter

#

- camshafts for use with stand alone injection setup

- no fuel lobe

- including adjustable sprockets for connecting chain (VVT sprocket can be used as well)

#

FOR COMPETITION APPLICATIONS ONLY. Following details must be verified:

-

the camshafs must turn smooth in the cylinderhead, provide free travel by machining where needed

-

distance between valve seal and retainer at full lift must be 0.6mm at least

-

minimum valve spring travel of 1.0mm at full lift must be provided

-

distance between valve and piston 1.0mm (pref. 1.5mm). check 5-15° before TDC on exhaust, and after TDC on intake

#

VVT reprogramming, operating range adjustment or even eliminating the VVT system should be considered for camshafts with increased duration

#

ONLY for use in competition engines with independent engine management (throttle position sensor) or carburettors

#

for BIG TURBO conversion (std to big turbo)
