REMARKS :
#
Both intake and exhaust cam driven by adjustable belt pulley (like oem exhaust cam). Without sprockets in the middle of the camshafts for connecting chain.
Pulley kit CTPO968 includes 2 cam pulleys, 1 crankshaft pulley and a Gates distribution belt.
#
Distance between valve and piston should be 1.0mm at least:
-
check 5-15° after TDC on intake
-
check 5-15° before TDC on exhaust
Machine pistons if required. Wrong installation can cause severe engine damage!
#
ECU reprogramming required
