REMARKS :
#
Camshafts are based on standard camshafts:
- intake 06H (109) 101D
- exhaust 06H 109 102 AD
Compatible with EA888 1.8L and 2.0L engines with following properties:
- intake VVT only
- cylinderhead with separate exhaust ports and exhaust manifold
- WITHOUT switching valve lift system (AVL) on exhaust camshaft
#
Camshaft set includes vvt sprocket on the intake cam, and adjustable sprocket on the exhaust cam.
#
valve seals must be lowered. Distance between valve seal and retainer must be at least 0.6mm at full lift.
#
ECU reprogramming required
#
these profiles are not compatible with stock pistons:
-
intake valve pocket: std depth +1mm
