REMARKS :
#
- cam lobe sequence: EI-EI-EI-EI (crossflow head)
- total length: 384mm (without water pump drive)
- double chain
- journal diameters: 37.94 - 37.94 - 37.94 - 34.48mm
#
FOR COMPETITION APPLICATIONS ONLY. Following details must be verified:
-
the camshafs must turn smooth in the cylinderhead, provide free travel by machining where needed
-
distance between valve seal and retainer at full lift must be 0.6mm at least
-
minimum valve spring travel of 1.0mm at full lift must be provided
-
distance between valve and piston 1.0mm (pref. 1.5mm). check 5-15° before TDC on exhaust, and after TDC on intake
#
ONLY for use in competition engines with independent engine management (throttle position sensor) or carburettors
#
check std valve spring setup for coil bind length and use valve spring kit if required
