REMARKS :
#
- camshafts for use in AQP-AUE (2.8L) engines with connecting chain and VVT tensioner between intake and exhaust
#
check distance between valve seal and retainer to be at least 0.6mm at full lift
#
for TURBO conversion (atmospheric to turbo)
#
Distance between valve and piston should be 1.0mm at least:
-
check 5-15° after TDC on intake
-
check 5-15° before TDC on exhaust
Machine pistons if required. Wrong installation can cause severe engine damage!
#
lock or limit range of VANOS system
#
ONLY for dirt track applications and pro street use with adjustable engine management or carburettors
#
engine with hydraulic rocker arm studs. To use camshafts with mechanical profiles, mechanical studs MUST be used. In case of doubt, please contact your distributor
