REMARKS :
#
In the TU roller engine, at least two different O.E.M. Camshaft types are being used:
1/ 27,65mm base circle - 5,90mm cam lift
2/ 30,00mm base circle - 5,25mm cam lift
When ordering, please indicate the type of camshaft of your engine.
For camshafts with higher cam lift, the base diameter is reduced to slide through the bearings during installation
#
bearing diameters: 42.42 - 41.82 - 41.23 - 40.62 - 36.92mm
#
in the TU roller engine, at least two different O.E.M. Camshaft types are being used:
1/ 27,65mm base circle - 5,90mm cam lift
2/ 30,00mm base circle - 5,25mm cam lift
when ordering, please indicate the type of camshaft of your engine
#
camshaft with 30,00mm base circle
#
ONLY for dirt track applications and pro street use with adjustable engine management or carburettors
