REMARKS :
#
camshafts for 2nd generation 3S-GE engines. Please check following dimensions before ordering:
- cam base diameter: 28mm or 32.5mm, check before ordering
- cam follower diameter: 31.0mm
- shim diameter: 28.0mm (between cam and follower)
#
FOR COMPETITION APPLICATIONS ONLY. Following details must be verified:
-
the camshafs must turn smooth in the cylinderhead, provide free travel by machining where needed
-
distance between valve seal and retainer at full lift must be 0.6mm at least
-
minimum valve spring travel of 1.0mm at full lift must be provided
-
distance between valve and piston 1.0mm (pref. 1.5mm). check 5-15° before TDC on exhaust, and after TDC on intake
#
ONLY for use in competition engines with independent engine management (throttle position sensor) or carburettors
