- chilled cast iron camshafts

- supplied with adjustable chain sprocket on the exhaust cam to optimize intake cam timing

(also available with 2 non adjustable chain sprockets at reference cam timing: partnumber 10156xx hydraulic or 10157xx mechanical)

mechanic 20v / 30v kit includes:

-

intake: tappets (ref. CC016), single springs (ref. 902-0013) on OEM upper retainer; 3/cyl each

-

exhaust: tappets (ref.CC019), double springs (ref. 902-2009) on OEM upper retainer or on aluminum retainer (ref. 99357); 2/cyl each

- valve clearance is to be adjusted using mechanical lash caps

-

please make sure that the lash cap does not touch the valve locks !

FOR COMPETITION APPLICATIONS ONLY. Following details must be verified:

-

the camshafs must turn smooth in the cylinderhead, provide free travel by machining where needed

-

distance between valve seal and retainer at full lift must be 0.6mm at least

-

minimum valve spring travel of 1.0mm at full lift must be provided

-

distance between valve and piston 1.0mm (pref. 1.5mm). check 5-15° before TDC on exhaust, and after TDC on intake
